BeiJer E50 - Transmission Speed Settings for AJ71;A1 SJ71

C-5
Transmission speed setting AJ71QC24/A1SJ71QC24/A1SJ71QC24-R2
SW08 OFF Setting change Allow Prohibit –
SW09 OFF Transmission
speed setting
Refer to the table below –
SW10 ON
SW11 ON
SW12 OFF
SW13-15 OFF – Set all to OFF Placed on the
left side of the
AJ71QC24(N)
Baud
rate
300 600 1200 2400 4800 9600 19200
SW09 OFF ON OFF ON OFF ON OFF
SW10 OFF OFF ON ON OFF OFF ON
SW11 OFF OFF OFF OFF ON ON ON
SW12 OFF OFF OFF OFF OFF OFF OFF
Switch
Default
comm.
settings in
software to
E-series
Setting items
Position of Setting
Switch
Notes
ON OFF
