Technical data
Technical data for E50, E100, E150 and E200
Parameter E50 E100 E150 E200
Front panel,
WxHxD, mm
104 x 69 x 4.5 142 x 90 x 3.5 142 x 100 x 3.5 147 x 163.5 x 5
Mounting
depth, mm
Excl. D-sub 38
Incl. D-sub 38
Excl. D-sub 28
Incl. D-sub 96.5
Excl. D-sub 28
Incl. D-sub 96.5
Excl. D-sub 38
Incl. D-sub 107
Panel cut out,
see drawing
S-02857 S4-03205 S-03258 S4-02809
Front panel
seal
IP 65, NEMA 4, NEMA 4X (Indoor use only)
Rear panel
seal
IP 20
Keyboard
material
Membrane keyboard with polyester snap discs. Overlay film of Autotex
F207 with print on reverse side. 1 million operations. See Appendix D.
Reverse side
material
Alu-Zink
Weight, excl.
D-sub
0.2 kg 0.5 kg 0.5 kg 0.7 kg.
Serial port
RS422
25-pin D-sub contact, chassis mounted female with standard locking
screws 4-40 UNC.
Serial port
RS232C
9-pin D-sub con-
tact, chassis
mounted male
with standard
locking screws 4-
40 UNC, availa-
ble when the
delivered con-
verter 232-25-
ADP is mounted
on the RS422
port.
9-pin D-sub contact, chassis mounted male with stand-
ard locking screws 4-40 UNC.
Flash memory
for application
16 kb 64 kb 64 kb 64 kb
