B-3
Connection to a C24 module in the MELSEC PLC system
See Appendix C for settings on a C24 module.
AJ71QC24/AJ71QC24N
AJ71C24/A1SJ71QC24/A1SJ71C24-R4/A1SJ71UC24-R4
A1SJ71QC24/A1SJ71C24-R2/A1SJ71UC24-R2/A1SJ71QC24-R2
RS422
RS232C
E-C24-232-CAB, See Appendix F
Terminal
RS422
RS232C
E-C24-422-CAB, See Appendix F
Termina l
RS422
RS232C
Cable 1
Terminal
To Next Page
