A-3
Technical data for E300, E600, E610 and E615
Ambient tem-
perature
0° to +50°C
Storage tem-
perature
-20° to +70°C
Relative
humidity
Max 85% non-condensed.
EMC tests on
the terminal
The terminal conforms with the essential protection requirements in article
four of the directive 89/336/EEC. Noise tested according to: EN50081-1
emission and EN61000-6-2 immunity.
UL approvals UL 508, UL 1604 (Class I Div 2)
DNV approval Det Norske Veritas type approval certificate. Location classes: Tempera-
ture A, Humidity B, Vibration A, Enclosure C (panel front only).
MTBF (Mean
time between
failure) (h)
402 225 345 155 345 155 128 062
Parameter E300 E600 E610 E615 E615T
Front panel,
WxHxD, mm
211.5 x 198 x
5,7
214 x 232 x
5.0
200 x 150 x
5.0
200 x 150 x
5.0
200 x 150 x
5.0
Mounting
depth, mm
Excl. D-sub
69
Incl. D-sub
110
Excl. D-sub
69
Incl. D-sub
110
70 70 70
Panel cut out,
see drawing
S4-02721 S4-03509 S-03611 S-03611 S-03611
Front panel
seal
IP 65, NEMA 4, NEMA 4X (Indoor use only)
Rear panel
seal
IP 20
Keyboard
material/
Front panel
Membrane keyboard with
polyester snap discs. Over-
lay film of Autotex F207 with
print on reverse side. 1 mil-
lion operations. See Appen-
dix D.
Polyester on glass and Autotext F207.
Touch screen. 1 million operations. See
Appendix D.
Reverse side
material
Yellow-chromated steel plate
Parameter E50 E100 E150 E200
