Stand fan / User Manual
7 / 12 EN
2 Installaton nstructons
1
2
3
1
2
3
Front and rear guard installation
Align catch of the front guard with the
illustrated position of the rear guard.
Press guards sequentially with both
hands.
Self-catch installation
234
1
1. Front grill
2. Lock nut of blade
•
Lock nut of blade anticlockwise, and then install the front fan cover.
3. Blade
•
Pull the blade to rotate after installing, so as to ensure that the blade can be normally rotated.
4. Lock nut of grill
•
Screw the lock nut of grill clockwise, and in the meantime, fix the rear grill.
