Belimo EPIV Series User Manual

V3.3 07.2016•Subject to modifi cation
UL marked actuators is optional, please contact your local Sales Representative for details.
17
P6..W..E-MP Mounting Instructions
AC 24 V / DC 24 V
Y
U
1 32 5
– +
T
~
Y
U
1 32 5
– +
T
~
DC (0)2...10V
DC 2...10V
Sensor / DC (0)2...10V
MP / DC 2...10V
Y2
Y1
≥ 5 x DN
90° 90°
