Belkin PRO - Operation Modes

FRONT PANEL
REAR PANEL
Power
Switch
Port Select Button
Bank Select/Scan Button
Current Active
Bank Display
Current Active
Port Displays
4
Product Detail
SLAVE INPUT
DB25 daisy-chain port
master input/slave output
DB25 daisy-chain port
Current Active
Bank Display
Current Active
Port Display
Bank Select/Scan Button
Port
Select/Scan
Button
Power
Switch
PC Port Connectors
DC power
jack.
DIP
Switches
Keyboard
Connector
P/S 2 Mouse
Connector
Keyboard
Output
Combo (PS/2 mouse or
serial mouse) output
VGA signal
output
VGA Monitor Connector
F1D116_OSD_AM_man.qxd 4/20/00 4:07 PM Page 4
