17
Note:
1. These dimensions are valid for products,which are hinged on right hand side.
2. When door opening direction is reversed, mirror image of this instruction should be
considered. That is, dimensions should be considered for opposite sides.
B
E
E = 1,5 mm is recommended.
Top view
Front view
E
B = 25 mm minimum.
320
B
9
8
20
20
= =
