FOR STREET / STRIP APPLICATIONS:
NOTE:
IN THE 1993 ACCUMULATOR HOUSING:red
3/8"
IN THE 1994-2006 ACCUMULATOR HOUSING:
red 3/8"
CHECK THE PISTON-SPACER STACKUP (STREET / STRIP
CONFIGURATION ONLY):
REASSEMBLE THE TRANSMISSION
APPLICATIONS ONLY)
Step 32
ACCUMULATOR HOUSING
RED 3/8" SPACER
YELLOW 5/8" SPACER
GASKETS & SEPARATOR PLATE
BLUE 3/4" SPACER
ACCUMULATOR HOUSING
RED 3/8" SPACER
WHITE 3/8" SPACER
GASKETS & SEPARATOR PLATE
BLUE 3/4" SPACER
CHECK
BALL
3-4 SPRING
(HEAVY
DUTY ONLY)
TEMPORARY
ALIGNMENT
SCREWS
