Benchmark BCT24M - 8. Specifications

99
Quick Reference Information
Engine Oil
Type
SAE 10W-30,API SE or SF, for general use
Capacity
0.5L (0.132 US Gal, 0.110 Imp Gal)
Spark Plug
Type
F7RTC or other equivalents.
Gap
0.028－0.031 in (0.70－0.80 mm)
Carburetor
Idle speed
1800±150 rpm
Maintenance
Each use
Check engine oil. Check air filter.
First 5
hours
Change engine oil.
Subsequent
Refer to the maintenance
8. SPECIFICATIONS
ENGINE SPECIFICATIONS
Model
1P75F
Type
Single cylinder, 4-Stroke, Forced Air Cooling,
OHV
Net power(kW/3600rpm)
4.5
Net torque (N·m/rpm)
14 / 2500
Bore x Stroke(mm)
75 × 50.8
Displacement
224 cc
Lubricating mode
Splash
Starting Mode
Recoil start/Electric start
Rotation
Anti-clockwise(from P.T.O. side)
Igniting Mode
Transistorized magneto Ignition
Dimension(L×W×H)(mm)
384 × 341 × 258
Net weight
12.4 Kg
The power rating of the engine indicated in this document is the net power output
tested on a production engine for the engine model and measured in accordance
with SAE J1349 at 3,600 rpm (Net Power) and at 2,500 rpm (Net Torque). Mass
production engines may vary from this value. Actual power output for the engine
installed in the final machine will vary depending on numerous factors, including
the operating speed of the engine in application, environmental conditions,
maintenance, and other variables.
