3
FIGURE 5: M-30
™
MODULATOR NON ANTILOCK APPLICATION OF SERVICE BRAKES
SUPPLY OR
HOLD
DIAPHRAGM
SPRING
BRAKE
CHAMBER
BRAKE VALVE
HOLD
VALVE
EXHAUST
DIAPHRAGM
EXHAUST
VALVE
EXHAUST PORT
BIAS
VALVE
FIGURE 6: M-30
™
MODULATOR NON ANTILOCK APPLICATION HELD POSITION
SUPPLY OR
HOLD
DIAPHRAGM
EXHAUST
VALVE
BIAS
VALVE
EXHAUST
PORT
HOLD
VALVE
BRAKE
CHAMBER
SPRINGSPRING
EXHAUST
DIAPHRAGM
BRAKE
VALVE
