Overview of Possible Issues (1.3)
Issue Description
Vehicle Diagnostic
Trouble Codes
(DTCs)
The Bendix Wingman Fusion system will not operate and will set a DTC if any of the
following vehicle systems also show a DTC: engine, engine cruise, instrument cluster,
Bendix
®
ABS, Bendix
®
ATC, Bendix
®
ESP
®
, or transmission. These components must be
repaired and cleared of DTCs before troubleshooting the Wingman Fusion system. (NOTE:
Clearing the vehicle DTCs may be the only step needed to reestablish full Fusion system
functionality. See Section 2.6: Clearing Diagnostic Trouble Codes (DTCs).
System familiarity Verify the system functionality. Is it operating normally or not? Drivers who are unfamiliar with
the system may report dissatisfaction over the way it beeps or how it activates the brakes.
Use Section 1.0: Introduction to Troubleshooting, Section 1.1: Troubleshooting Basics, and
Section 2.5: Diagnostic Trouble Codes to verify if the system is functioning normally; then
continue.
DTCs caused by
temporary operating
conditions
Some DTCs indicate a temporary condition and will clear when that condition is no longer
present. If these persist, further investigation is warranted.
See Section 1.1: Troubleshooting Basics.
Radar sensor
blocked
If the system doesn’t seem to work at all, the radar sensor may possibly be blocked. If the
radar is blocked, an alert should be issued to the driver to indicate this condition. Visually
inspect the area around the radar, clear the blockage, turn the ignition on and run through a
power cycle. See Appendix A3 for more information about radar mounting and clearances.
Damaged radar
sensor or bracket
If the vehicle has been in an accident, it is likely the radar sensor will need to be re-aligned
or replaced. Inspect the radar sensor and housing for damage. Radar sensor discoloration
will require radar sensor replacement. Regardless of the exterior condition, check for DTCs
outlined in the Section 2.5: Diagnostic Trouble Codes (DTCs) to determine if radar sensor
replacement is necessary.
Damaged connector
or wiring
2.7: Troubleshooting Diagnostic Trouble Codes: Power Supply and 2.8 Serial Data (J1939)
Communications Link of this document for additional troubleshooting.
Radar sensor
misalignment
Inspect the front of the vehicle. If a) it has been damaged; or b) the vehicle does not track
straight, either of these conditions must be repaired before troubleshooting the Bendix Wingman
Fusion system.
If there is a DTC set or if the system does not function, the radar sensor may be severely
misaligned and the Wingman Fusion system will not operate until this is corrected. See
Appendix B - Radar Alignment.
J1939 network
problems
If the entire system is non-functional, it may be a J1939 network problem. Follow the
instructions in Section 2.8: Serial Data (J1939) Communications Link.
Power to radar
sensor problems
If the entire system is non-functional, another likely cause may be a lack of power to the radar sensor.
Follow the instructions in Section 2.7: Troubleshooting Diagnostic Trouble Codes: Power Supply.
Call the Bendix Tech Team at 1-800-AIR-BRAKE (1-800-247-2725), option 2 for troubleshooting assistance.
Table 3 – Overview of Possible Issues
1.3 OVERVIEW OF POSSIBLE ISSUES
Some customer issues are actually misunderstandings of how the Bendix
®
Wingman
®
Fusion
™
system performs normally.
Use Table 3 below to learn the causes of potential issues if the Fusion system is not performing correctly. Some issues
can be investigated by a visual inspection. Others may cause a Diagnostic Trouble Code (DTC) to be logged: See Section
2.5: Diagnostic Trouble Codes.
