Benelli TNT125 Service Manual

Make the tail of main
cable pass through the
inside of frame and tie
it at the frame
Make the ECU wire of
main cable go into the
side of frame from here
Make main cable pass
through the battery and
air filter
Tie the relay wire
and oxygen sensor
wi
re at the frame
using a fastener
here
- 468 -

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
