EC declaration of confirmity
Manufacturer: Automatismi Benincà SpA.
Address: Via Capitello, 45 - 36066 Sandrigo (VI) - Italia
Herewith declares that: control unit HEADY.
complies with the following relevant provisions:
EMC guidelines: 89/336/CCE, 93/68/CEE
Low voltage guidelines: 73/23/CEE, 93/68/CEE
Benincà Luigi, Legal responsible.
Sandrigo, 12/12/2010.
WARNINGS
This manual has been especially written to be use by qualified
fitters.
None of the information provide in this manual can be
considered as being of interest for the end users.
Preserve this manual for future needs.
The technician has to furnish all the information related to
the step by step function, the manual and the emergency
function of the operator, and to deliver the manual to the
final user.
;
Foresee on the supply net an onnipolar switch or
selector with distance of the contacts equal or
superior to 3 mms.
Verify that of the electrical system there is an awry differential
interrupter and overcurrent protection.
Some typologies of installation require the connection of
the shutter to be link at a conductive mass of the ground
according to the regulations in force.
The electrical installation and the operating logic must
comply with the regulations in force.
The leads fed with different voltages must be physically
separate, or they must be suitably insulated with additional
insulation of at least 1 mm.
The leads must be secured with an additional fixture near
the terminals.
During installation, maintenance and repair, interrupt the
power supply before opening the lid to access the electrical
parts
Check all the connections again before switching on the
power.
The unused N.C. inputs must be bridged.
The descriptions and the present illustrations in this manual
are not binding. Leaving the essential characteristics of
the product unchanged, the manufacturer reserves himself
the right to bring any change of technical, constructive or
commercial character without undertaking himself to update
the present publication.
TECHNICAL DATA
Mains power supply
230 VAC 50/60 Hz (115VAC 50/60 Hz for HEADY 115)
Output, Motor
1/2 motor 230VAC (115V for HEADY 115)
Motor maximum power
500W + 500W
Output, power supply of accessories
24VDC 500mA max.
Protection level
IP54
Operating temperature
-20∞C / +70∞C
Radio receiver
433,92 MHz, incorporated and configurable
No. of codes storable in memory
64
WASTE DISPOSAL
If the product must be dismantled, it must be disposed
according to regulations in force regarding the differentiated
waste disposal and the recycling of components (metals,
plastics, electric cables, etc..).
For this operation it is advisable to call your installer or a
specialised company.
