BENOIT SYSTEMS Light Drive 2 - Page 6

Update : 28/11/2018
Index : 03 Version : 00
5
Central unit and electronics unit nomenclature
Num.
Ref.
Qty/unit
Name
1
270-015
1
NVR2 plastic cover
2a
2b
210-080
210-020
1
NVR2 electronics unit
VR2 electronics unit (compatible with dual
attendant control)
3
A00-118
2
M4x20 flat head screw
4
A00-395
2
Spacer Ø6 length 30
5
A00-136
2
M6x45 flat head screw
6
210-030
1
50A power cable
7
000-630
4
M6x20 button head screw
8
280-037
1
U-shaped reinforcement
9
000-605
2
M6x25 button head screw
10
000-525
4
M5x10 button head screw
11
280-035
1
Sliders support
12
A00-058
4
M8x16 button head screw
13
000-850
4
Serrated washer Ø8
14
100-410
1
Central tube (different colours see page 14)
15
280-011
2
Polished central collars
16
280-060
2
Upper handle bearing
17
A00-074
2
M5x20 flat head screw
18
200-080
1
Upper handle
19
200-086
2
Polished upper handle side
20
000-530
2
M5x16 button head screw
21
A00-138
2
M6x25 hex head screw
22
000-690
2
Washer Ø 6
23
200-050
2
Battery slider
24
000-610
6
Locknut M6
25
280-021
1
Polished rear handle
26
A00-059
2
M6x25 flat head screw
27
280-051
1
Polished rear handle plate
28
A00-023
6
M6x16 flat head screw
29
A00-477
2
Washer Ø5
30
000-200
1
Red connector
31
730-035
1
Controller bracket plate
32
A00-310
4
M4x12 flat head screw
33
740-010
1
Black washer Ø5
34
A00-440
2
M5x16 low head screw
35
730-025
1
Controller bracket
