Q7T3-FP737S-Dual function LCD Monitor Service
Engineering Specification
16
Confidential
See figure below
Measurement is done on position 1.
Viewing angle origine is the axis normal to the flat panel. Left (L) and Right (R) valu
are the maximum angles for which CR=10. Up (U) and (D) value are the maximum
angles for which CR=10.
Normal
E
y
È
Ö
x
Ö = 0 , Right
Ö = 90 , Up
Ö = 180 , Left
Ö = 270 , Down
3.Contrast Ratio (CR) is defined mathematically as:
)0φ ,0θ(at
(Min.) el Black Levin Luminance
(Max.) LevelWhite in Luminance
oo
==
4. Response time
TrR measures the transition time of L1 relative luminance from white to black state, from 90% to 10% (see graph
below)
TrD measures the transition time of L1 relative luminance from black to white state, from 10% to 90% (see graph
below)
5. Cross talk shall be measured between two patterns.
100%
90%
TrR TrD
WHITE
BLACK
10%
0%
t
WHITE
