BENZING M2 User Manual

To use the complete functions of
the BENZING Live Smart Hub it’s
necessary to set GPS time in the
ClubSystem.
RCL/GPS:
Select with up and down GPS.
Conrm with OK.
Select Offset:
With left and right you manage the
offset. With up and down you choose
GPS and RCL.
It’s needed that the GPS and RCL
offset is set to the same offset.
Operation l Operatie l Operación l Funcionamento

Power supply
Power
(110 - 240 VAC, 50 Hz)
BENZING ClubSystem
Printer
PC
PC Connections
(USB or RS 232 serial)
Radio clock/GPS
BENZING M2/M3
Time Set in the Clubsystem Menu
Club installation
Connect the BENZING M2/M3 to the ClubSystem
using a club cable. Check if everyone required
components such as printer, PC connection and
external time source are connected. Then connect
the plug-in power supply to the ClubSystem.
EN
Instalación del Club
Conecte el BENZING M2/M3 al ClubSystem con un
cable club. Compruebe si todos los componentes
necesarios, como la impresora, la conexión de PC
y la fuente de tiempo externa, están conectados.
Luego conecte el complemento fuente de
alimentación al ClubSystem.
ES
Instalação na Colectividade
Ligue o BENZING M2/M3 ao ClubSystem utilizando
o cabo fornecido com o ClubSystem. Verique se
todos os dispositivos estão ligados (impressora,
ligação ao PC e o dispositivo de acerto de hora)
Depois é só ligar o cabo do transformador ao
ClubSystem.
PT
FOR CLUB
Club installatie
Verbind de BENZING M2/M3 met het Clubsysteem
met behulp van een clubkabel. Controleer de
componenten zoals printer, pc-verbinding en Atoom-
klok/Gps ontvanger zijn aangesloten. Sluit vervol-
gens de voedings adapter aan op het Clubsysteem.
NL
EN JPNNL ES PT
