22
Insert the handle (item 1) into the support (item 2) as
shown.
Install the handle (item 1) on the control rod (item 3)
as shown and secure with a 2.5 mm hair pin (item 4).
Install handle
Reinstall the helper spring as originally installed.
Raise the blade. Pull up the tension arm (item 1).
This spring helps to lift the blade with little effort.
Note: If the blade does not scrape enough, remove
the helper spring.
VERIFY TIRE PRESSURE:
Check and adjust tractor tire pressure as follows:
Front tires: 14-15 psi
Back tires: 7-8 psi
Tire pressure must be even on both sides of the
tractor.
Apply tension on helper spring
ASSEMBLY
