Beretta CIAO e 24 C.S.I. - Multigas Performance Tables

CIAO e
13
Multigas table
DESCRIPTION Methane gas (G20) Butane (G30) Propane (G31)
LowerWobbeindex(at15°C-1013mbar) MJ/m
3
S 45,67 80,58 70,69
NetCaloricValue MJ/m
3
S 34,02 116,09 88
Supplynominalpressure
mbar
(mmW.C.)
20
203,9
28-30
285,5-305,9
37
377,3
Supplyminimumpressure
mbar
(mmW.C.)
13,5
137,7
- -
CIAO 24 C.S.I. e
Diaphragm(numberofholes) n° 11 11 11
Diaphragm(diameterofholes) mm 1,35 0,78 0,78
Heatingmaximumgascapacity Sm
3
/h 2,73
kg/h 2,03 2,00
DHWmaximumgascapacity Sm
3
/h 2,73
kg/h 2,03 2,00
Heatingminimumgascapacity Sm
3
/h 0,94
kg/h 0,70 0,69
DHWminimumgascapacity Sm
3
/h 0,94
kg/h 0,70 0,69
Maximum pressure downstream CH valve mbar 11,80 27,80 35,80
mm W.C. 120,33 283,48 365,06
Maximum pressure downstream DHW valve mbar 11,80 27,80 35,80
mm W.C. 120,33 283,48 365,06
Minimum pressure downstream CH valve mbar 1,50 3,30 4,30
mm W.C. 15,30 33,65 43,85
Minimum pressure downstream DHW valve mbar 1,50 3,30 4,30
mm W.C. 15,30 33,65 43,85
CIAO 28 C.S.I. e
Diaphragm(numberofholes) n° 14 14 14
Diaphragm(diameterofholes) mm 1,35 0,76 0,76
Heatingmaximumgascapacity Sm
3
/h 3,19
kg/h 2,38 2,35
DHWmaximumgascapacity Sm
3
/h 3,19
kg/h 2,38 2,35
Heatingminimumgascapacity Sm
3
/h 1,34
kg/h 1,00 0,99
DHWminimumgascapacity Sm
3
/h 1,11
kg/h 0,83 0,82
Maximum pressure downstream CH valve mbar 9,70 27,80 35,80
mm W.C. 98,91 283,48 365,06
Maximum pressure downstream DHW valve mbar 9,70 27,80 35,80
mm W.C. 98,91 283,48 365,06
Minimum pressure downstream CH valve mbar 1,90 5,40 6,90
mm W.C. 19,37 55,06 70,36
Minimum pressure downstream DHW valve mbar 1,30 3,70 5,00
mm W.C. 13,26 37,73 50,99
CIAO 24 C.A.I. e
Diaphragm(numberofholes) n° 12 12 12
Diaphragm(diameterofholes) mm 1,35 0,77 0,77
Heatingmaximumgascapacity Sm
3
/h 2,82
kg/h 2,10 2,07
DHWmaximumgascapacity Sm
3
/h 2,82
kg/h 2,10 2,07
Heatingminimumgascapacity Sm
3
/h 1,10
kg/h 0,82 0,81
DHWminimumgascapacity Sm
3
/h 1,10
kg/h 0,82 0,81
Maximum pressure downstream CH valve mbar 10,10 28,00 36,00
mm W.C. 102,99 285,52 367,10
Maximum pressure downstream DHW valve mbar 10,10 28,00 36,00
mm W.C. 102,99 285,52 367,10
Minimum pressure downstream CH valve mbar 1,7 4,7 6,10
mm W.C. 17,34 47,93 62,20
Minimum pressure downstream DHW valve mbar 1,7 4,7 6,10
mm W.C. 17,34 47,93 62,20
