BERMAD FP 400E - Page 8

BERMAD Fire Protection
400 Series
FP 400E Installation, Operation & Maintanence
Valve Disassembling Parts Breakdown
Lifting Ring
Body
Diapragm
Assembly
Cover
Disk
Bolt
Bolt
Va lve name plate
bermadfire@bermad.com • www.bermad.com
The information herein is subject to change without notice. BERMAD shall not be held
liable for any errors. All rights reserved. © Copyright by BERMAD. PT4PE08-DATA
8
