6
Specications
Attention: The MATRIX 360° is a class 2 laser according to United States Government
Code Of Federal Regulations CFR21.
Do not look directly into the laser beam to avoid permanent eye damage.
Attention: Never charge the accumulators unattended.
Attention: Charge the accumulators according to their specications.
Charging time is 4 hours, remove the charger afterwards!
Attention: Never short-circuit the accumulators!
Attention: Never break up the accumulatios nor expose them to heat or re!
Warranty
Warranty is 12 month on defect in material and workmanship. The warranty will not apply to
this product if it has been altered or abused. Without limiting the forgoing, battery leakage,
damages to the plastic housing, broken optic windows, damage to the switch/LED membrane
are presumed to result from misuse or abuse. Tampering with or removal of the caution or
certications labels voids this warranty. Attempts at repair or detectable improper treatment
will void any warranty claim. During the warranty period and upon proof of purchase, the
product will be replaced or repaired. All technical specications of the divece and accessories
might be altered at any time and may differ from data sheets or this manual.
Laser class 2, 635nm - 670nm, < 1 mW
Accuracy ± 1,5 mm / 10 m
Horizontal line 360°
Compensator electronic
Self levelling range ± 4°
Self levelling speed < 4 s
Horizontal drive 360°
Working range 30 m
Power supply 4 x 1,2 V AA - Accu
Operating time > 8 h
Out-of-level-warning Laser line pulsating
Operating temperature - 10° C bis 40° C
Tripod connection 5/8“
Dimensions Ø 150 mm x 220 mm
Weight 1,3 kg
Protection class IP54
How to use the MATRIX 360°
Laser class 2
CEI 60825-1 (2007)
≤ 1 mW ; 635 - 670 nm
