EN
112
10 12 15
1/4" Quilting foot available as optional
accessory.
- Set stitch length control between "2" - "4".
- P
attern selector on " " or " ".
- Ce
nter needle position.
Procedure:
Seam allowance 1/4 inch (6 mm)
Place the fabric under the presser foot so
that the raw edges are aligned with the seam
guide sew seam by guiding the fabric along
the guide so that perfect 1/4 inch seams are
stitched.
Seam allowance 1/8 inch (3 mm)
Position the fabric under the foot raw edges
aligned with the outer edge of the right toe
(see arrow). Stitch perfect 1/8 inch seams.
The notches on the left edge of the foot
are 1/4 inch in front and behind the needle
located. The centre notch is in line with the
point of needle penetration. The markings
are helpful when the patchwork seam should
start or end 1/4 inch in from the fabric edge.
Caution:
This foot can only be used with straight
s
t
itch in centre position.
Please note:
No "S" marking is shown on the stitch length
dial by model 10.
Quilting
