Betta ATLANTIS BACK ENTRY - Technical Specifications; P Trap and S Trap Configurations; Water Inlet and Pipe Details; Installation Guide

90
180
275
170
750
210
220
180
FIXATION BRACKETS
TECHNICAL DRAWINGS
810
420
Finish the frame. The outside of the frame is often tiled to create a cohesive bathroom design.
“P”TRAP & “S”TRAP
The Atlantis has the option of using a “P” Trap
or “S” Trap pipe.
WATER INLET AND PIPE
BACK ENTRY
WATER INLET
STEP 2
2
3
STEP 1
STEP 3
Please make sure
your water inlet,
outlet pipe
and pan xation
are as to the specied
measurements.
BACK ENTRY
WATER INLET
Cable must be on
the right hand side
as shown.
31
44
Wirquin back
entry installed
mechanism
(Atlantis cistern).
All the
mechanism are
set for 3/4.5L
ushing.
210
105
210
90
160
105
210
“P” Trap
“S” Trap
Please note that
the water inlet pipe
is only on the left
hand side.
