BETTE SILHOUETTE - Section B: Initial Installation Steps; Bathtub Placement and Securing; Section C: Plumbing Connections and Measurement Checks; Waste Fitting Installation

2
BETTESILHOUETTE
INSTALLATION
B
C
Ø 300
460
430
Kontrolle / Control
Contrôle / Controle
je nach Option
depending on option
selon option choisie
zie opties
➊
➊
➋
➋
➌
➊
➋
bei "ohne Option"
at "without option"
chez "sans option"
bij "zonder opie"
Abflußgarnitur montieren
install waste
installer la bonde
afvoergarnitur monteren
1/2" x 16
DN50 / DN40
