Installation and User Guide
EV Charger | 202205.NH www.syncev.co.uk
1
3
2
4
110mm
Cable entry
145mm
Ensure the supplied caps are tted over installation
screws to maintain IP rating
Ensure supplied cord grip is tted on incoming power
cable if using bottom cable entry location.
Ensure connector is fully inserted, then clip
power connector into the base.
Use included hole template to drill xing holes
Ensure correct polarity when making
incoming power connections
LEN
5 6
