USE
Connecting the cable reel
1. Unroll the cable to the desired length in order to operate consumers with a total output up to
1,000 W.
2. Completely unroll the cable in order to operate consumers with a total output of more than 1,000
W up to 3,000 W.
3. Avoid tripping points when routing the cable.
4. Insert the mains plug of the cable reel into a mains socket fused and earthed correctly.
5. Check if the consumer is switched off and insert the mains plug of the consumer into the earthing
contact socket of the cable reel.
Thermal protection switch
The cable reel is equipped with a thermal protection switch which interrupts the power circuit in event
of overheating. The thermal protection switch can be tripped if the cable reel has not been completely
unrolled or the maximum rated power of the consumer is too high.
If the thermal protection switch has been activated, proceed as follows:
1. Disconnect the earthing contact plug (7) of the product from the earthing contact socket.
2. Disconnect the consumer from the earthing contact socket (4) of the product.
3. Unroll the cable over its entire length.
4. Allow the cable to cool down.
5. Press in the thermal protection switch (8).
6. The product can be used again once the cable has cooled down.
Faults / malfunctions
If a malfunction should occur, please check the following points:
• Check the cable for damage.
• Has the mains plug been plugged into a correctly safeguarded and earthed socket?
• Has the thermal protection switch been activated?
Deactivate the thermal protection switch as described above.
TRANSPORT
If you transport the product incorrectly, the product may be damaged.
Observe the following information for transporting the product:
• Completely roll up the cable.
• Fix the plug into cable holder (6).
• Make sure that the brake system of the reel prevents the cable from unrolling unintentionally.
STORAGE
If you store the product incorrectly, the product may be damaged.
If the product is not used, observe the following storage conditions:
• Store the product dry and protected against frost and heat.
• Store the product in an area protected against dust and direct sun radiation.
• If necessary, store the product in a cover, which protects against the ingress of dust.
• The storage temperature corresponds with the range specified in the chapter
″TECHNICAL DATA″.
