Bieffe BF091 - Page 45

45
ASSE NELLA MANICA and JOLLY IRONING BOARD
L1 N
PE
ref EV I1 I2 M1 PL1 PL2 PR RS1 RS2 RS3 SP1 SP2 TR1 TR2 TR3
description SOLENOID VALVE IRON SWITCH BOILER SWITCH VACUUM MOTOR PEDALBOARD MICRO IRON MICROSWITCH PRESSURE SWITCH BOARD HEATER BOILER HEATER IRON HEATER STEAM READY LIGHT LOW WATER LEVEL LIGHT BOARD THERMOSTAT HEATER BOILER THERMOSTAT HEATER IRON THERMOSTAT
wired diagram “ASSE NELLA MANICA” system 2LT COD. BF070B
Bieffe srl
may 2012
RS3
I1 I2
EV
TR2
TR2

PR
TR1
PL1
M1
RS1
TAVOLO
STEAM IRON BIEFFE
TR3
BOILER
RS2
SP1
P
SP1
ENGLISH
15. WIRING DIAGRAM BF070
