1. T-Square
®
Fence
2. Support Leg (2)
3. Leveling Foot (2)
4. 3/8-16 Hex Nut (2)
5. #8 x 5/8” Pan HD Screw (12)
6. #10-32 X 3/8” RND HD Screw (2)
7. Flat Washer (2)
8. Hairline Pointer
9. Knob
For Attaching Front Rail to Delta Unisaw/Contractor
Saw/Hybrid Saw
10. 5/16-18 x 1-1/4” Flat HD Screw (2)
11. 3/8 Lock Washer (2)
12. 3/8 Flat Washer (2)
13. 5/16-18 Hex Nut (2)
For Attaching Extension Table (All Saws)
18. 1/4-20 x 1-1/2” Flat HD Screw (14)
19. Fender Washer (14)
20. 1/4-20 Hex Nut (14)
For Attaching Front & Rear Rail to Non Delta Saws
21. 1/4-20 x 1-1/4” Flat HD Screw (10)
22. 1/4” Lockwasher (10)
23. 1/4” Flat Washer (10)
24. 1/4-20 Hex Nut (10)
For Attaching Guide Tube to Front Rail
25. 1/4-20 X 1/2” Hex HD Screw (7)
26. 1/4” Lock Washer (7)
27. Template
For Attaching Rear Rail to Delta Hybrid Saw and Left-Tilt
Contractor’s Saw ONLY
28. 8MM x 1” Hex HD Screw (2)
29. 8MM Lock Washer (2)
30. 8MM Flatwasher (2)
3
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18 19 20
21 22 23 24
25
26
27
28
29 30
For Attaching Rear Rail to Delta Unisaw/Right-tilt
Contractors Saw
14. 3/8-24 x 1-1/4” Hex HD Screw (2)
15. 3/8 Lock Washer (2)
16. 3/8 Flat Washer (2)
17. 3/8-24 Hex Nut (2)
