BIFFI WGR 200 - 2.2 Main Parts Description

WGR – Worm Gear Reducer
Instruction and operating manual
© Copyright by BIFFI Italia. All right reserved MAN 684/Rev 5 Page 8
2.2 Main Parts Description
Picture 1
Picture 2
Main Reduction Case
Epicyclical Reduction Case
Mechanical Stoppers
Close Position Label
Open Position Label
Position Indicator
WGR Identification and
Characteristics Label
Closing Direction Label
