10.3 Refilling procedure (only for WGR-DW series models)
Please refer to the following Picture 13
 Remove both the oil plugs (1) with a hex-head wrench
 Refill by pouring the oil inside one hole (the other hole is used for pressure compensation)
Picture 13
(1) Oil plugs
