OWNER'S MANUAL - PARTS IDENTIFICATION
Hardware Components
|
5/16
| T-NUT BLKH100379
(x152)
(x116)
H100198 | WASHER LOCK EXT BLK
|
8x19
(x8)
H100195
| BOLT WH BLK
|
5/16x2-3/4
H100630 | WASHER FLAT BLK
(x48) | 8x19
(x24)
H100200
| SCREW PFH BLK
|
8x1-1/2
H100202
| SCREW PWH BLK
(x4) | 8x5/8
(x12)
H100792
| LAG SCREW WH BLK
|
1/4x3
(x24)
H100120 | CONCRETE ANCHOR
|
1/4x2
(x16)
H100205
| BOLT WH BLK
|
5/16x2-1/4
(x80)
H100391
| SCREW PFH BLK
|
8x2
H100653 | NUT LOCK BLK
(x24) | 1/4
(x8)
H101058
| BOLT WH BLK
|
5/16x8-3/4
H100382 | SCREW PFH BLK
(x112) | 8x1-3/4
H100459 | BOLT WH BLK
(x48) | 5/16x1-1/4
H100415| BOLT WH BLK
(x32) | 5/16x3-3/4
(x12)
H100405 | WASHER LOCK EXT BLK
|
6x15
(x12)
H100197
| LAG SCREW WH BLK
|
5/16x2-1/2
H100488
| BOLT WH BLK
(x24) | 1/4x2
(x48)
H100471
| LAG SCREW WH BLK
|
5/16x1-1/2
