Bilt Backyard Discovery WHISPERING POINT - Page 26

STEP 5 - ROPE WALL
TIP:
INSTALL T-NUTS IN WOOD FIRST
QTY
PART NUMBER DESCRIPTION
8 H100201 SCREW PFH 8x2 1/2" BLK
2
H100379
T-NUT 5/16 BLK
ATTACHMENT BOARD - W4L18228
1"x3 3/8"x23 7/8" (24x86x606)
H17
(x1)
201 (x8)
SCREW - 2 1/2"
H17
T-NUTS TO THE INSIDE OF
BOARD WHEN INSTALLED
SIDE VIEW
T-NUT
HOLES DOWNWARD
H17 (x1)
379 (x2)
T-NUT - 5/16"
26
