Bilt Backyard Discovery WHISPERING POINT - Page 53

STEP 7 - FORT ASSEMBLY
387 (x8)
SCREW - 1 1/4"
M01 (x2)
QTY
PART NUMBER DESCRIPTION
8 H100387 SCREW PFH 8x1 1/4 BLK
PICKET - W4L18251
5/8"x3 3/8"x23 7/8" (16x86x606)
M01
(x2)
1 1/8 in
[28
mm]
2 in
[52 mm]
2 7/8 in
[72 mm]
PICKET PAL
(x1)
A6P00410
INSIDE VIEW
PICKETS EVENLY SPACED.
53
