STEP 28 - FORT ASSEMBLY
J05 (x2)
H10 (x1)
200 (x14)
SCREW - 1 1/2"
WINDOW TRIM - W4L18275
1"x3 3/8"x47 1/8" (24x86x1198)
H10
(x1)
WINDOW TRIM - W4L18278
1"x2"x26 1/4" (24x50x668)
J05
(x2)
2 1/2 in
[64
mm]
FLUSH
(TOP & BOTTOM)
QTY
PART NUMBER DESCRIPTION
14
H100200 SCREW PFH 8x1 1/2 BLK
INSIDE VIEW
H11 (x1)
WINDOW TRIM - W4L18494
1"x3 3/8"x47 1/8" (24x86x1198)
H11
(x1)
74
