Caution
The use of the wrong mains equipment may damage your device. You should only use
the power supply unit provided! If you require foreign adapters/mains units, please
contact our bintec elmeg service.
Incorrect cabling of the ISDN and ETH interfaces may also damage your device. Con-
nect only the ETH interface of the device to the LAN interface of the computer/hub or a
WAN interface if available and the ISDN interface of the device only to the ISDN con-
nection.
Note
If you connect an unconfigured device to an ISDN connection in parallel to a PBX, the
PBX cannot take any calls until an ISDN number is configured on the device. If no
entry is specified, every incoming ISDN call is accepted by the ISDN Login service.
Fig. 16: Connection options using the example of bintec RS232jw
When setting up and connecting, carry out the steps in the following sequence (refer to the
3 Installation bintec elmeg GmbH
34 bintec RS Series
