5
Front Panel and Key Features
Key Functions
1. Power On/Off Button
2. MODE Button
3. UP Button
4. DOWN Button
5. LED Readout
6. Chamber Number LED
7. Garment Connector Bar Ports
8. Auxiliary Connector Bar Ports (shown with Blocker Bars)
5
6
1
2
3
4
7
8
