Bio-Tek FL600 - Page 35

3-10
Bio-Tek FL600
FAN
PMT
LAMP
EXCITATION
FILTER
WHEEL
EMISSION
FILTER
WHEEL
INCUBATOR
BOTTOM
PROBE
Y-AXIS SCREW
DOOR
POWER
SUPPLY
TOP
PROBE
MICROPLATE
X-AXIS SCREW
SET SCREWS
TOP PROBE
PROBE HEIGHT ADJUSTMENT JIG
SET SCREW
FL600 TOP PROBE POSITION
(side view)
TOP PROBE ADJUSTMENT JIG
(top view)
FL600 INTERIOR CONFIGURATION
0,&523/ $7 (
5 mm probe
1-3 mm probe
Figure 3-6: FL600 interior configuration
