Technical Information
5-11
)/6HULDO&RPPXQLFDWLRQV
The reader communicates with the computer via a 9-pin D-type male-female
connector (P/N 75034).
The connector is wired as follows.
PIN Computer FL600
1 DCD Not used
2 RX TX data to computer
3 TX RX data from
computer
4 DTR Not used
5 GND Signal ground
6 DSR Not used
7 RTS Linked to pin 8
8 CTS Linked to pin 7
9 RI Not used
Serial Port
Parameter
KC4 Reader
Control and Data
Reduction
Software
FL600
Diagnostic
Software
Baud rate 9600 9600
Data bits 8 8
Parity Even None
Stop bit 1 1
Note: The FL600 Diagnostic Software settings can not be changed- through
either software or hardware tools.
