12. To attach the safety harness, pull on the red tabs to open the harness attachment clips. Attach
the harness and snap the clips back together to secure.
CONTENTS
— 9— ASSEMBLY INSTRUCTIONS
Figure 2. Lay the left and right support legs
on the floor next to the top frame assembly.
Figure 3. Slide the Top Frame Assembly
into the support legs.
Figure 4. Insert patient support handles into the
handrail receiving tubes.
Figure 5. Attach the Safety Harness.
