Biostar H67MH Setup Manual

Motherboard Manual
2
1.3 MOTHERBOARD FEATURES
TH67MU3 / H67 MU3 H67 MH
CPU
Socket 1155
Intel Core i7 / i5 / i3 / Pentium p rocessor
Supports Execute Disable Bit / Enhanced Intel
SpeedStep® / Intel Architecture-64 / Extended
Memory 64 Technology / Virtualization
Technology
Socket 1155
Intel Core i7 / i5 / i3 / Pentium p rocessor
Supports Execute Disable Bit / Enhanced Intel
SpeedStep® / Intel Architecture-64 / Extended
Memory 64 Technology / Virtualization
Technology
Chipset
Intel H67 Intel H67
Super I/O
ITE 8728
Provides the most common ly used legacy Super
I/O functionality.
Low Pin Count Interface
Environment Control in it iatives ,
Hardware Monitor Controller
Fan Speed Contro ller
ITE's "S mart Guardian" funct ion
ITE 8728
Provides the most common ly used legacy Super
I/O functionality.
Low Pin Count Interface
Environment Control in it iatives ,
Hardware Monitor Controller
Fan Speed Contro ller
ITE's "S mart Guardian" funct ion
Main Memory
DIMM Slots x 2
Each DIMM supports 512MB / 1GB / 2GB / 4GB
DDR3
Max Memory Capacity 8GB
Dual Channel Mode DDR3 memory module
Supports DDR3 1333/1066
Registered DIMM and ECC DIMM is not
supported
DIMM Slots x 2
Each DIMM supports 512MB / 1GB / 2GB / 4GB
DDR3
Max Memory Capacity 8GB
Dual Channel Mode DDR3 memory module
Supports DDR3 1333/1066
Registered DIMM and ECC DIMM is not
supported
SATA 2 & 3
Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s / 6.0 Gb/s.
SATA Version 2.0 / 3.0 specification compliant
Integrated Serial ATA Controller
Data transfer rates up to 3.0 Gb/s / 6.0 Gb/s.
SATA Version 2.0 / 3.0 specification compliant
LAN
Realtek RTL8111E
10 / 100 Mb/s / 1Gb/s auto negotiation
Realtek RTL8111E
10 / 100 Mb/s / 1Gb/s auto negotiation
Sound Codec
ALC662
5.1 channels audio out
High Definition Audio
ALC662
5.1 channels audio out
High Definition Audio
USB3.0
Asmedia ASM1042
PCI Express Gen2 x16 Slot x1 PCI Express Gen2 x16 Slot x1
PCI Express Gen2 x1 Slot x1 PCI Express Gen2 x1 Slot x1
Slots
PCI Slot x2 PCI S lot x2
Printer Port Connector x1 Printer Port Connector x1
Serial Port Connector x1 Serial Port Connector x1
SATA 3 Connector x2 SATA 3 Connector x2
SATA 2 Connector x4 SATA 2 Connector x4
Front Panel Connector x1 Front Panel Connector x1
Front Audio Connector x1 Front Audio Connector x1
S/PDIF out Connector x1 S/PDIF out Connector x1
On Board
Connectors
CPU Fan Header x1 CPU Fan Header x1
