BITO WS-L - Page 39

WEITSPANNREGAL | WIDE SPAN SHELVING
39
2
FB
A = 72 mm
B
=
=
=
B
B
T
A = 72 mm
T (mm) FB (mm)
1 2 3
A (mm) B (mm)
max.
600
1.350
WT 67L
-3
72
600
1.800 - 4 550
2.200 1 5 550
2.700 1 5 650
2.700 WT 69L 7 450
T (mm) FB (mm)
1 2 3
A (mm) B (mm)
max.
800
1.350
WT 67L
-3
72
600
1.800 - 4 550
2.200 1 5 550
2.700 1 5 650
2.700 WT 69L 7 450
T (mm) FB (mm)
1 2 3
A (mm) B (mm)
max.
1.100
1.350
WT 67L
-4
72
400
1.800 - 5 450
2.200 1 5 550
2.700 1 5 650
2.700 WT 69L 7 450
1
WT 67L
1.
2.
2
=
=
69 mm
67 mm
23 mm23 mm
WT 67L WT 69L
1
4
1
1
2
2
3
