BIXOLON SPP-R200II Command Manual

SPP-R200II Command Manual
Rev. 1.00 BIXOLON
- 49 -
• Table 1 [Enlarged in horizontal direction]
Hex
Decimal
Enlargement
00
0
1 time (standard)
10
16
2 times
20
32
3 times
30
48
4 times
40
64
5 times
50
80
6 times
60
96
7 times
70
112
8 times
• Table 2 [Enlarged in vertical direction]
Hex
Decimal
Enlargement
00
0
1 time (standard)
01
1
2 times
02
2
3 times
03
3
4 times
04
4
5 times
05
5
6 times
06
6
7 times
07
7
8 times
Remarks:
■ The character size set by this command is valid for alphanumeric, user-defined characters, multi-byte code
characters such as Chinese, Japanese, and Korean.
■ Double width and double height modes can be set by ESC !.
■ Multi-byte code characters are specified only by this command.
■ The setting of this command remains effective until ESC @, printer reset or power cycling is executed.
Differences:
None

BIXOLON SPP-R200II Specifications

General

Type	Mobile printer
Print technology	Direct thermal
Maximum resolution	203 x 203 DPI
Compatible operating systems	Windows XP/Vista/Server 2003/2008/7/8\\r OPOS\\r Linux CUPS
Flash memory	32 MB
Internal memory	64 MB
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 93, EAN13, EAN8, ITF, MaxiCode, PDF417, QR Code, UPC-A, UPC-E
Maximum printing width	50 mm
USB port	Yes
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Connectivity technology	Wired
Dimensions (WxDxH)	79.5 x 43.6 x 126.7 mm
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	-15 - 50 °C
Operating relative humidity (H-H)	10 - 80 %
Ethernet LAN	No
Battery voltage	7.4 V
Power source type	Battery
Battery life (max)	6.2 h
