BIXOLON SRP-382 User Manual

SRP-382
Rev. 1.00
- 29 -
5-4-2 2d Barcodes
Windows driver supports two-dimensional barcode fonts as shown in the following table.
Barcodes can be printed on the printer by using following font names.
Font Name
Type (Symbology)
Size (Point)
2D-Code1
PDF417
8.5
2D-Code2
QR Code
8.5
If you want to change the default value of 2d barcode properties, select a Font Name and
Type of two-dimensional barcode, and then click Properties. Click OK after changing the
values of properties for PDF417 or QR Code.
<PDF417>
<QR Code>

BIXOLON SRP-382 Specifications

General

Type	POS printer
Print technology	Direct thermal
Product color	Black
Bluetooth	Yes
USB 2.0 ports quantity	1
Connectivity technology	Wired
Ethernet LAN	No
Maximum roll diameter	83 mm
Supported paper width	80/58 mm
Maximum printing width	72 mm
Printing media thickness	0.062 - 0.075 µm
Size (imperial)	3 \
Sustainability certificates	ENERGY STAR
AC input voltage	100-240 V
Power source type	AC
AC input frequency	50-60 Hz
Flash memory	64 MB
RAM capacity	0.128 GB
Built-in barcodes	1D, 2D
Autocutter durability	3 million cuts
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Mobile operating systems supported	Android, iOS

Weight and Dimensions

Depth	148 mm
Width	147 mm
Height	200 mm
