KNG Portable Radio User’s Manual
- 11 -
Status Indicators
Monitor Mode
Flashing indicates Normal Mode in digital operation
Open Audio
Voice Mute Enabled
Alphanumeric Label Options
NOTE: Three channel information lines are programmable with PC Radio Editor.
Channel Number Channel Number of Currently Selected Channel
or Active Scanned Channel
Channel Label Alphanumeric Label of Currently Selected
Channel or Active Scanned Channel
Frequency Operating Frequency of Currently Selected
Channel or Active Scanned Channel
Unit ID Shows your P25 Unit ID
While receiving, the ID of the radio transmitting
the message is displayed
If the received ID is programmed in your radio's
Call List, the corresponding label will be displayed
Received Talk Group ID P25 Talk Group ID of the radio transmitting the
message currently being received
Pick List Selection* NAC, TGID or Code Guard currently selected
from the programmable Pick Lists
Zone Label Label of Currently Selected Zone
Zone and Channel Currently Selected Zone and Channel Numbers
Zone Number Currently Selected Zone Number
RX/TX Key Currently selected encryption key
Subaudible* Displays CxCSS value of received signal
DTMF* Displays the numeric DTMF tones of received
signal
*Conventional Channels Only

BK Radio KNG Series Specifications

General

Channels	Up to 1000 channels
Channel Spacing	12.5 kHz, 25 kHz
GPS	Optional
Frequency Range	136-174 MHz (VHF), 380-520 MHz (UHF), 764-870 MHz (700/800 MHz)
Battery Type	Lithium-Ion
Operating Temperature	-30°C to +60°C (-22°F to +140°F)
Modulation	FM, P25
Encryption	DES
P25 Compliance	Yes
