Black & Decker 1720 User Manual

2
5
4
3
2
1
11
10
9
8
7
6
14
12
15
16
13
17
18
19
20
FIG. 1 FIG. 2
21
Parts Description (Figures. 1,2 )
FIG. 1 1. Operating Handle
2. Guard
3. Saw Blade
4. Miter Clamp Handle
5. Miter Latch
6. Miter Scale
7. Left Side Fence and
Clamping Knobs
8. Bench Mounting Holes
FIG. 2 9. Dust Spout
10. Bevel Clamp Knob
11. Bevel Scale Pointer
12. Bevel Scale
13. Bevel Stop
14. Lock Down Pin
15. Hand Indentation
16. Right Side Fence
17. Kerf Slot
18. Motor Housing
19. Spindle Lock Button
20. Trigger Switch
21. Brush Inspection Cap
154791 / 1720 miter saw 2/2/00 11:49 AM Page 2
