d. Store idle power tools out of the reach
of children and do not allow persons
unfamiliar with the power tool or these
instructions to operate the power tool.
Power tools are dangerous in the hands of
untrained users.
e. Maintain power tools. Check for
misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tools operation.
If damaged, have the power tool repaired
before use. Many accidents are caused by
poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to
control.
g. Use the power tool, accessories and
tool bits etc., in accordance with these
instructions and in the manner intended
for the particular type of power tool, taking
into account the working conditions and
the work to be performed. Use of the power
tool for operations different from those intended
could result in a hazardous situation.
5. Service
a. Have your power tool serviced by a
qualifi ed repair person using only identical
replacement parts. This will ensure that the
safety of the power tool is maintained.
Additional safety instructions for impact drills
• Wear ear protectors with impact drills.
Exposure to noise can cause hearing loss.
• Use auxiliary handles supplied with the tool.
Loss of control can cause personal injury.
• Hold power tool by insulated gripping
surfaces when performing an operation
where the cutting tool may contact hidden
wiring or its own cord. Contact with a “live”
wire will also make exposed metal parts of the
power tool “live” and shock the operator.
• Use clamps or another practical way to
secure and support the workpiece to
a stable platform. Holding the work by hand or
against your body leaves it unstable and may
lead to loss of control.
• Before drilling into walls, fl oors or ceilings
check for the location of wiring and pipes.
• Avoid touching the tip of a drill bit just after
drilling, as it may be hot.
Electrical safety
This tool is double insulated; therefore
no earth wire is required. Always check
that the power supply corresponds to the
voltage on the rating plate.
• This appliance is not intended for use by young
or infi rm persons without supervision. Children
must be supervised to ensure they do not play
with the appliance.
• If the supply cord is damaged, it must be
replaced by the manufacturer or an authorised
Black & Decker Service Centre in order to
avoid a hazard.
Features
This tool includes some or all of the following
features.
1. Variable speed switch
2. Lock-on button
3. Forward/reverse slider
4. Drilling mode selector
5. Chuck
6. Depth stop
7. Side handle
Assembly
Warning! Before assembly, make sure that the tool
is switched off and unplugged.
Fitting the side handle and depth stop (fi g. A)
• Turn the grip counterclockwise until you can
slide the side handle (7) onto the front of the
tool as shown.
• Rotate the side handle into the desired
position.
• Insert the depth stop (6) into the mounting hole
as shown.
• Set the drilling depth as described below.
• Tighten the side handle by turning the grip
clockwise.
Fitting a drill bit or screwdriver bit
Keyless chuck (fi g. B)
• Open the chuck by turning the front part (8)
with one hand while holding the rear part (9)
with the other.
• Insert the bit shaft (10) into the chuck and fi rmly
tighten the chuck.
Keyed chuck (fi g. C)
• Open the chuck by turning the sleeve (11)
counterclockwise.
• Insert the bit shaft (10) into the chuck.
