Chapter 1: Specifications
Wallplate Transmitter (continued)
Audio
Input (1) 3.5-mm mini jack, stereo audio binding with VGA
input
Supported Audio
Format
HDMI: Stereo, LPCM 5.1 LPCM 7.1, Dolby True HD,
DTS-HD Master Audio;
VGA: Stereo
General
Environment
Operating
Temperature
32 to 113° F (0 to 45° C)
Storage
Temperature
-4 to +158° F (-20 to +70° C)
Humidity 10 to 90%, noncondensing
ESD Protection Human-body model
±8 kV (air-gap discharge)/4 kV (contact discharge)
Power
Power Supply 12 VDC, 1.5 A/PoH
Power
Consumption
(Maximum)
3.36 W, powered by HDBaseT receiver with POH
Mechanical
Dimensions 4.16"H x 3.58"W x 1.16"D (10.56 x 9.1 x 2.94 cm)
Weight 0.48 lb. (0.22 kg)
Approvals CE, FCC, RoHS, PoH
