TOOLS NEEDED: Phillips head screwdriver
& Adjustable wrench
TOOL NEEDED:
Phillips head screwdriver
TOOL NEEDED:
Adjustable wrench
TOOLS NEEDED: Phillips head screwdriver
& Adjustable wrench
ENGLISH
NOT INCLUDED:
20 lb (9 kg) LPG tank & AA Battery
NOT INCLUDED:
20 lb (9 kg) LPG tank
NOT INCLUDED:
20 lb (9 kg) LPG tank & AA Battery
NOT INCLUDED:
20 lb (9 kg) LPG tank
NOT INCLUDED:
AA Battery
NOT INCLUDED:
1 lb (453 g) LPG bottle
ENGLISH
ASSEMBLY GUIDE
ILLUSTRATED PARTS LIST
1 Body (1 piece) 2 Griddle top & Hood (1 piece) 3 Bottom shelf (1 piece)
4 Side shelves
(2 pieces)
5 Grease cup
(1 piece)
6 Caster
wheels (2 pieces)
7 Control
knobs (2 pieces)
8 Upper
propane hanger
(1 piece)
9 Lower
propane support
(1 piece)
10 Hood
handle (1 piece)
11 Shear pin
(1 piece)
12 Cotter pin
(1 piece)
13 Large
thumb screw
(1 piece)
14 Medium
thumb screw
(1 piece)
15 Small
thumb screws
(2 pieces)
16 M6x12
Screws (4 pieces)
