Mounting the Carrier to the Hitch Receiver
1. Slide the clamping block (G) over the end of the hitch tube. Make sure the large, open end of the
clamping block faces the hitch receiver on the vehicle.
2. With assistance, lift the empty carrier and slide the open end of the hitch tube into thehitch
receiver. Secure with the hitch pin and clip (K).
3. Slide the clamping block up against the hitch receiver. Tighten the bolts against the underside of
the hitch receiver collar.
Operation
1. Remove the lock pin to unlock the ramp.
2. Remove the ramp and place the end rung onto the
hook end of the platform, making sure the ramp is
securely in place. The bottom end of the ramp must
rest flat on a solid, level surface when loading and un-
loading equipment.
3. Measure the motorcycle wheelbase to make sure the
wheel pins are in the appropriate positions.
4. Shift the motorcycle into neutral and, with another per-
son’s assistance, push it up the ramp. Push the motor-
cycle completely onto the carrier platform until the front
wheel rests in place between the platform rungs.
5. Properly secure the motorcycle using tie down straps
(sold separately).
6. Return the ramp to the mounted position and secure
with the lock pin.
7. Attach any needed markers and/or lights to the
carrier and motorcycle as required by vehicle codes.
