1.SD/MMC card input 3. Play/Pause/Scan(FM)
2. USB 2.0 input 4. Playback Mode Selector
5. Track Repeat
6. Previous Track/Volume Down
7. Next Track/Volume Up
8. LCD Display 13. Mic Talk over selector
9. XLR Mic input 14. ¼” Mic/Guitar input
10. RCA stereo input 15.Mic 1/Guitar(Mic 2) gain level
11. RCA stereo output 17. Mic. Echo effect level
12. MP3/Line in selector 18. Master Volume control
16. Line/MP3 gain level 19. 5 band Equalizer
20. VHF Mic 1 gain level 21. VHF Mic 2 gain level
22. VHF System power control 23. 12 Volt Power/Ground input
24. VHF antenna for MIC 1 25.VHF antenna for MIC 2
26. AC Power connection 27. Input Voltage selector
28. Battery status indicator
29. Master Power switch 30. Battery (do not remove)
31. Speaker Stand input
To Next Page
